23355 Model A Chassis, Stage 3, Kick-up Coil-over Rear style

23355 Model A Chassis, Stage 3, Kick-up Coil-over Rear style

  • $ 7,48000

Please contact us if you are interested in this product.
Please include product information in email.
21103 T-Frame, w/ front Perch (20" Bed or Sportdeck)

#23355

Model A Chassis, (1928-1931), Stage 3, Kick-up Coil-over Rear style.

STAGE 3 Chassis includes

  • Frame Rails with Front Crossmember & Kicked-up Rear Crossmember, (raised & narrowed), (Stage 1)
  • Hood and Body Tabs
  • Motor Mount Frame Brackets
  • Vega Steering Box Mount, with gusset
  • Front 4-Bar Frame Brackets
  • Front Panhard Bar Mount Bracket
  • Rear 4-Bar Frame Brackets
  • Transmission Crossmember with Drop-out Tabs
  • Master Cylinder Bracket with Pedal Pivot & Gusset Tab
  • Upper Rear Coil-Over Mounts
  • Rear Panhard Bar Mount Bracket
  • Front Shock Mounts
  • Brake Line Adapter Tabs (4), (Inverted Flare or AN style)

  • Front U-Bolt Plate & Bolt Kit *
  • Front Multi-Leaf Spring *
  • Front Shackles *
  • Extended Spring Perches *
  • Front Tube Axle, (or I-Beam, (at extra cost) *
  • Axle Batwings *
  • Front Shocks & Mounting Bolt Kit *
  • Front, Lower Shock Mounts *
  • Spindles with Bushings & Kingpins Installed *
  • Lower Steering Arms *
  • Front 4-Bars with Ends and Bushings *
  • Front Panhard Rod with Ends *
  • Tie Rod with Ends *
  • Vega Style Steering Box, New
  • Pitman Arm *
  • Drag Link with Ends *

  • Transmission Drop-out Bracket, (specify style)
  • Master Cylinder, (disc/drum or disc/disc)
  • Brake Pedal Arm
  • Brake Pedal Push Rod Kit *
  • Rear 4-Bars with Ends and Bushings *
  • Rear 4-Bar Support Gussets *
  • Rear 4-Bar & Coil-over Housing Brackets
  • Rear Adjustable Coil-Over Shocks *
  • Rear Coil-Over Shocks Bolt and Spacer Kit *
  • Rear Panhard Bar with Ends *
  • Rear Panhard Bar Housing Mount Bracket *

    • Items included with Chrome Package when added *

    **Due to the extreme price increases on tubing, brackets and other supplies from vendors, our frames have gone up significantly. We are sorry for this, but it's out of our control**

    Stage 3 Chassis are built to order (to a specific Body Style, Motor/Trans and style of Radiator) and can require at least 8 to 10 weeks lead time** (Chassis can be will-called or shipped by Truck) contact CCR for more information and shipping quotes



       Printable (prices on the PDF's are not correct)

      Please call (909-393-4005) or Email (ccrhotrods@yahoo.com)
